1、 高效离心风机和优化设计的风道结构提供强大气流保障布草平整、舒展及顺畅送布。 High efficient centrifugal fan and the optimization design of air duct structure provide strong airflow to ensure linen smooth, stretch and feed.
2、 人工操作时间大大减少,可提高工作效率及降低工作强度。 Manual operation time is greatly reduced, can improve the work efficiency and reduce work intensity.
3、 展平效果明显,提高熨烫质量。 Flattening effect significantly, improve the quality of ironing.
4、 速度自动模式,可与烫平机同步控制。 Automatic mode, can be operate with the ironing machine.
5、 配置出料隔栅,提高传送效率。 Configuration of discharging the grille, make the transmission more efficiency.
6、 可调式旋钮控制器,操作便捷。 Adjustable knobs controller, make the operation more convenient.
7、 下导风结构,使噪音更低。 The ventilation structure, lower the noise.
8、 铰接式出料机结构便于送布机与烫平机对接,更适应客户不同布置要求。 Articulated discharging machine structure is easy to send machine and ironing machine, more adapt to the customer different layout requirements.
型号规格 Model | YCS-3000 | YCS-3300 |
有效送布宽度 (mm) Length of ironing roller | 3000 | 3300 |
送布速度 (meter/min) Speed of ironing | ≤60 | ≤60 |
功率 (kw) Power | 5 | 5 |
整机重量 (kg) Overall weight | 730 | 740 |
外形尺寸 (mm) Exterior dimension | 3536*1200*1260 | 3836*1200*1260 |
