1、 PLC控制系统,大液晶触摸屏,动态显示折叠状态,可实现人机对话功能,内储多套自动折叠程序。PLC control system, intelligent touch screen, dynamic display folding condition can realize man-machine dialog and reserve sets of folding program.
2、 两横三纵折叠功能,前三折用气刀,后两折用机械折刀。Two horizontal with three vertical function, first 3 step by pneumatic fold, later two step by mechanical folding knife.
3、 两套独立的驱动电机,由变频器控制,折叠速度在50米/分钟内无极可调功能,每小时可最多折叠1000条床单。Two sets of independent drive motor control by inverter, it is infinitely adjustable function within 50 meters/min folding speed per hour can realize fold article 1000 sheets per hour.
4、 高品质的静电消除棒,所有导布辊都做了特殊的防静电处理,有效减少布草上的静电,降低了布草起卷,起皱等问题,提高折叠率,增加机器的可靠性和稳定性。 High quality anti-static eliminate stick, all the guide roller with special destabilization to reduce static from linen effectively. Reduces clothes grass wrinkles and enhance the rate of folding, increase the reliability and stability of the machine.
型号规格 Model | ZD-3000 | ZD-3300 |
最大折叠宽度 (mm) Maximum folded width | 3000 | 3300 |
最多折叠层次 Maximum folding levels | 5/32 | 5/32 |
最大折叠速度 (m/min) Folding speed | 50 | 50 |
额定电压 (v/Hz) Rated voltage | 380/50 | 380/50 |
电机功率 (kw) Motor power | 1.87 | 1.87 |
整机重量 (kg) Overall weight | 1430 | 1630 |
外形尺寸 (mm) Exterior dimension | 4160*2930*1750 | 4460*293*1750 |
